External systems and apps steps

External systems actions allow your workflows to communicate with third-party services and custom endpoints. You can interact with external systems in the following ways:

Connector-based actions use Kibana's centralized Connectors framework. Before using them, you must first configure a connector.

The step type is a keyword for the service (for example, slack or jira). You must also provide a connector-id at the same level as type.

To view the available connectors, click Actions menu and select External Systems & Apps.

The connector-id field accepts one of the following:

  • The unique name you gave the connector (for example, "my-slack-connector"). This is the recommended method for readability.
  • The connector's raw ID (for example, "d6b62e80-ff9b-11ee-8678-0f2b2c0c3c68").

This example uses a pre-configured Slack connector named "security-alerts-channel".

steps:
  - name: notify_security_channel
    type: slack
    connector-id: "security-alerts-channel"
    with:
      message: "High-priority alert: {{ event.name }}. Please investigate immediately."

This example uses a Jira connector named "engineering-project".

steps:
  - name: create_jira_ticket
    type: jira
    connector-id: "engineering-project"
    with:
      projectKey: "ENG"
      issueType: "Task"
      summary: "Automated Task: Review '{{ event.name }}'"
      description: "Workflow '{{ workflow.name }}' requires manual review for a potential issue."

The native http action is a built-in HTTP client that does not require a pre-configured connector. Use it for one-off requests to public or internal APIs.

Use the following parameters in the with block to configure the request:

Parameter Required Description
url Yes The full URL of the endpoint to call
method No (defaults to GET) The HTTP method (GET, POST, PUT, or DELETE)
headers No An object with key-value pairs for HTTP headers
body No The request body (typically a JSON object)
Known limitation

The native http action does not have access to a centralized secret store for managing authentication credentials. If your endpoint requires authentication, you must include the credentials directly in the headers block.

Click to show syntax example
steps:
  - name: call_secure_api
    type: http
    with:
      url: "https://api.thirdparty.com/v1/data"
      method: "GET"
      headers:
        Authorization: "Bearer my-secret-api-token"

This example makes a POST request to a custom automation endpoint, passing data from the workflow context.

steps:
  - name: trigger_custom_automation
    type: http
    with:
      url: "https://hooks.example.com/services/T00000000/B00000000/XXXXXXXXXXXXXXXXXXXXXXXX"
      method: "POST"
      headers:
        Content-Type: "application/json"
      body:
        event_id: "{{ event.id }}"
        message: "Workflow action triggered by '{{ workflow.name }}'"
