container-logs

container-logs integration collects and parses logs of Kubernetes containers.

It requires access to the log files in each Kubernetes node where the container logs are stored. This defaults to /var/log/containers/*${kubernetes.container.id}.log.

By default only container parser is enabled. Additional log parsers can be added as an advanced options configuration.

You can customize the routing of container logs events and sending them to different datasets and namespaces, as well as enable preserve_original_event based on using pods' annotations.

Customization can happen at:

• pod definition time, e.g., using a deployment.
• pod runtime, annotating pods using kubectl.

Here is an example of an Nginx deployment where we set both elastic.co/dataset and elastic.co/namespace annotations to route the container logs to specific datasets and namespace, respectively.

# nginx-deployment.yaml
apiVersion: apps/v1
kind: Deployment
metadata:
  name: nginx-deployment
spec:
  replicas: 1
  selector:
    matchLabels:
      app: nginx
  template:
    metadata:
      annotations:
        elastic.co/dataset: kubernetes.container_logs.nginx
        elastic.co/namespace: nginx
        elastic.co/preserve_original_event: "true"
      labels:
        app: nginx
        app.kubernetes.io/name: myservice
        app.kubernetes.io/version: v0.1.2
        app.kubernetes.io/instance: myservice-abcxzy
    spec:
      containers:
        - name: nginx-container
          image: nginx:latest
          ports:
            - containerPort: 80

Suppose you want to change the container logs routing and enable preserve_original_event on a running container. In that case, you can annotate the pod using kubectl, and the integration will apply it immediately sending all the following documents to the new destination:

Here is an example where we route the container logs for a pod running the Elastic Agent to the kubernetes.container_logs.agents dataset:

kubectl annotate pods elastic-agent-managed-daemonset-6p22g elastic.co/dataset=kubernetes.container_logs.agents

Here's a similar example to change the namespace on a pod running Nginx:

kubectl annotate pods elastic-agent-managed-daemonset-6p22g elastic.co/namespace=nginx

Here is an example to enable preserve_original_event on a pod running Nginx:

kubectl annotate pods elastic-agent-managed-daemonset-6p22g elastic.co/preserve_original_event=true

You can restore the standard settings by removing the annotations:

kubectl annotate pods elastic-agent-managed-daemonset-6p22g elastic.co/dataset-
kubectl annotate pods elastic-agent-managed-daemonset-6p22g elastic.co/namespace-
kubectl annotate pods elastic-agent-managed-daemonset-6p22g elastic.co/preserve_original_event-

Here are the annotations available to customize routing:
