Cisco ISE


Version	1.26.1 (View all)
Compatible Kibana version(s)	8.11.0 or higher 9.0.0 or higher
Supported Serverless project types What's this?	Security Observability
Subscription level What's this?	Basic
Level of support What's this?	Elastic

The Cisco ISE integration collects and parses data from Cisco Identity Services Engine (ISE) using TCP/UDP.

Compatibility

This module has been tested against Cisco ISE server version 3.1.0.518.

Requirements

Enable the integration with the TCP/UDP input.
Sign in to Cisco ISE Portal.
Configure Remote Syslog Collection Locations.
- Procedure
  1. In Cisco ISE Administrator Portal, go to Administration > System > Logging > Remote Logging Targets.
  2. Click Add.
  3. Enter all the Required Details.
  4. Set the maximum length to 8192.
  5. Click Submit.
  6. Go to the Remote Logging Targets page and verify the creation of the new target.

Note

It is recommended to have 8192 as Maximum Message Length. Segmentation for certain logs coming from Cisco ISE might cause issues with field mappings.

Logs

Reference link for Cisco ISE Syslog: Here

log

This is the log dataset.

		{
    "@timestamp": "2020-02-21T19:13:08.328Z",
    "agent": {
        "ephemeral_id": "1c70d737-7545-456d-8fb9-7033dca67ed3",
        "id": "901f4c48-583a-4848-aa7b-89dc8e9c4b76",
        "name": "docker-fleet-agent",
        "type": "filebeat",
        "version": "8.10.2"
    },
    "cisco_ise": {
        "log": {
            "acct": {
                "request": {
                    "flags": "Stop"
                }
            },
            "acs": {
                "session": {
                    "id": "ldnnacpsn1/359344348/952729"
                }
            },
            "authen_method": "TacacsPlus",
            "avpair": {
                "priv_lvl": 15,
                "start_time": "2020-03-26T01:17:12.000Z",
                "task_id": "2962",
                "timezone": "GMT"
            },
            "category": {
                "name": "CISE_TACACS_Accounting"
            },
            "cmdset": "[ CmdAV=show mac-address-table <cr> ]",
            "config_version": {
                "id": 1829
            },
            "cpm": {
                "session": {
                    "id": "81.2.69.144Accounting306034364"
                }
            },
            "device": {
                "type": [
                    "Device Type#All Device Types#Routers",
                    "Device Type#All Device Types#Routers"
                ]
            },
            "ipsec": [
                "IPSEC#Is IPSEC Device",
                "IPSEC#Is IPSEC Device"
            ],
            "location": [
                "Location#All Locations#EMEA",
                "Location#All Locations#EMEA"
            ],
            "message": {
                "code": "3300",
                "description": "Tacacs-Accounting: TACACS+ Accounting with Command",
                "id": "0000000001"
            },
            "model": {
                "name": "Unknown"
            },
            "network": {
                "device": {
                    "groups": [
                        "Location#All Locations#EMEA",
                        "Device Type#All Device Types#Routers",
                        "IPSEC#Is IPSEC Device"
                    ],
                    "name": "wlnwan1",
                    "profile": [
                        "Cisco",
                        "Cisco"
                    ]
                }
            },
            "port": "tty10",
            "privilege": {
                "level": 15
            },
            "request": {
                "latency": 1
            },
            "response": {
                "AcctReply-Status": "Success"
            },
            "segment": {
                "number": 0,
                "total": 4
            },
            "selected": {
                "access": {
                    "service": "Device Admin - TACACS"
                }
            },
            "service": {
                "argument": "shell",
                "name": "Login"
            },
            "software": {
                "version": "Unknown"
            },
            "step": [
                "13006",
                "15049",
                "15008",
                "15048",
                "13035"
            ],
            "type": "Accounting"
        }
    },
    "client": {
        "ip": "81.2.69.144"
    },
    "data_stream": {
        "dataset": "cisco_ise.log",
        "namespace": "ep",
        "type": "logs"
    },
    "destination": {
        "ip": "81.2.69.144"
    },
    "ecs": {
        "version": "8.17.0"
    },
    "elastic_agent": {
        "id": "901f4c48-583a-4848-aa7b-89dc8e9c4b76",
        "snapshot": false,
        "version": "8.10.2"
    },
    "event": {
        "action": "tacacs-accounting",
        "agent_id_status": "verified",
        "category": [
            "configuration"
        ],
        "dataset": "cisco_ise.log",
        "ingested": "2023-10-03T09:31:56Z",
        "kind": "event",
        "original": "<182>Feb 21 19:13:08 cisco-ise-host CISE_TACACS_Accounting 0000000001 4 0 2020-02-21 19:13:08.328 +00:00 0018415781 3300 NOTICE Tacacs-Accounting: TACACS+ Accounting with Command, ConfigVersionId=1829, Device IP Address=81.2.69.144, CmdSet=[ CmdAV=show mac-address-table <cr> ], RequestLatency=1, NetworkDeviceName=wlnwan1, Type=Accounting, Privilege-Level=15, Service=Login, User=psxvne, Port=tty10, Remote-Address=81.2.69.144, Authen-Method=TacacsPlus, AVPair=task_id=2962, AVPair=timezone=GMT, AVPair=start_time=1585185432, AVPair=priv-lvl=15, AcctRequest-Flags=Stop, Service-Argument=shell, AcsSessionID=ldnnacpsn1/359344348/952729, SelectedAccessService=Device Admin - TACACS, Step=13006, Step=15049, Step=15008, Step=15048, Step=13035, NetworkDeviceGroups=Location#All Locations#EMEA, NetworkDeviceGroups=Device Type#All Device Types#Routers, NetworkDeviceGroups=IPSEC#Is IPSEC Device, CPMSessionID=81.2.69.144Accounting306034364, Model Name=Unknown, Software Version=Unknown, Network Device Profile=Cisco, Location=Location#All Locations#EMEA, Device Type=Device Type#All Device Types#Routers, IPSEC=IPSEC#Is IPSEC Device, Response={AcctReply-Status=Success; }, Network Device Profile=Cisco, Location=Location#All Locations#EMEA, Device Type=Device Type#All Device Types#Routers, IPSEC=IPSEC#Is IPSEC Device, Response={AcctReply-Status=Success; }",
        "sequence": 18415781,
        "timezone": "+00:00",
        "type": [
            "info"
        ]
    },
    "host": {
        "hostname": "cisco-ise-host"
    },
    "input": {
        "type": "filestream"
    },
    "log": {
        "file": {
            "device_id": 2080,
            "inode": 88860,
            "path": "/tmp/service_logs/log.log"
        },
        "level": "notice",
        "offset": 71596,
        "syslog": {
            "priority": 182,
            "severity": {
                "name": "notice"
            }
        }
    },
    "message": "2020-02-21 19:13:08.328 +00:00 0018415781 3300 NOTICE Tacacs-Accounting: TACACS+ Accounting with Command, ConfigVersionId=1829, Device IP Address=81.2.69.144, CmdSet=[ CmdAV=show mac-address-table <cr> ], RequestLatency=1, NetworkDeviceName=wlnwan1, Type=Accounting, Privilege-Level=15, Service=Login, User=psxvne, Port=tty10, Remote-Address=81.2.69.144, Authen-Method=TacacsPlus, AVPair=task_id=2962, AVPair=timezone=GMT, AVPair=start_time=1585185432, AVPair=priv-lvl=15, AcctRequest-Flags=Stop, Service-Argument=shell, AcsSessionID=ldnnacpsn1/359344348/952729, SelectedAccessService=Device Admin - TACACS, Step=13006, Step=15049, Step=15008, Step=15048, Step=13035, NetworkDeviceGroups=Location#All Locations#EMEA, NetworkDeviceGroups=Device Type#All Device Types#Routers, NetworkDeviceGroups=IPSEC#Is IPSEC Device, CPMSessionID=81.2.69.144Accounting306034364, Model Name=Unknown, Software Version=Unknown, Network Device Profile=Cisco, Location=Location#All Locations#EMEA, Device Type=Device Type#All Device Types#Routers, IPSEC=IPSEC#Is IPSEC Device, Response={AcctReply-Status=Success; }, Network Device Profile=Cisco, Location=Location#All Locations#EMEA, Device Type=Device Type#All Device Types#Routers, IPSEC=IPSEC#Is IPSEC Device, Response={AcctReply-Status=Success; }",
    "related": {
        "hosts": [
            "cisco-ise-host"
        ],
        "ip": [
            "81.2.69.144"
        ],
        "user": [
            "psxvne"
        ]
    },
    "tags": [
        "preserve_original_event",
        "forwarded",
        "cisco_ise-log"
    ],
    "user": {
        "name": "psxvne"
    }
}



Field	Description	Type
@timestamp	Event timestamp.	date
cisco_ise.log.acct.authentic		keyword
cisco_ise.log.acct.delay_time		long
cisco_ise.log.acct.input.octets		long
cisco_ise.log.acct.input.packets		long
cisco_ise.log.acct.output.octets		long
cisco_ise.log.acct.output.packets		long
cisco_ise.log.acct.request.flags		keyword
cisco_ise.log.acct.session.id		keyword
cisco_ise.log.acct.session.time		long
cisco_ise.log.acct.status.type		keyword
cisco_ise.log.acct.terminate_cause		keyword
cisco_ise.log.acme-av-pair.audit-session-id		keyword
cisco_ise.log.acme-av-pair.service-type		keyword
cisco_ise.log.acs.instance		keyword
cisco_ise.log.acs.session.id		keyword
cisco_ise.log.active_session.count		long
cisco_ise.log.ad.admin		keyword
cisco_ise.log.ad.domain.controller		keyword
cisco_ise.log.ad.domain.name		keyword
cisco_ise.log.ad.error.details		keyword
cisco_ise.log.ad.forest		keyword
cisco_ise.log.ad.hostname		keyword
cisco_ise.log.ad.ip		ip
cisco_ise.log.ad.log		keyword
cisco_ise.log.ad.log_id		keyword
cisco_ise.log.ad.organization_unit		text
cisco_ise.log.ad.site		keyword
cisco_ise.log.ad.srv.query		keyword
cisco_ise.log.ad.srv.record		keyword
cisco_ise.log.adapter_instance.name		keyword
cisco_ise.log.adapter_instance.uuid		keyword
cisco_ise.log.admin.interface		keyword
cisco_ise.log.admin.session		keyword
cisco_ise.log.airespace.wlan.id		long
cisco_ise.log.allow.easy.wired.session		keyword
cisco_ise.log.allowed_protocol.matched.rule		keyword
cisco_ise.log.assigned_targets		keyword
cisco_ise.log.auth.policy.matched.rule		keyword
cisco_ise.log.authen_method		keyword
cisco_ise.log.authentication.identity_store		keyword
cisco_ise.log.authentication.method		keyword
cisco_ise.log.authentication.status		keyword
cisco_ise.log.average.radius.request.latency		long
cisco_ise.log.average.tacacs.request.latency		long
cisco_ise.log.avpair.disc.cause		long
cisco_ise.log.avpair.disc.cause_ext		long
cisco_ise.log.avpair.elapsed_time		long
cisco_ise.log.avpair.pre_session_time		long
cisco_ise.log.avpair.priv_lvl		long
cisco_ise.log.avpair.start_time		date
cisco_ise.log.avpair.stop_time		date
cisco_ise.log.avpair.task_id		keyword
cisco_ise.log.avpair.timezone		keyword
cisco_ise.log.called_station.id		keyword
cisco_ise.log.calling_station.id		keyword
cisco_ise.log.calling_station_id		keyword
cisco_ise.log.category.name		keyword
cisco_ise.log.cause		keyword
cisco_ise.log.cisco_av_pair.coa-push		boolean
cisco_ise.log.cisco_av_pair.cts-device-capability		keyword
cisco_ise.log.cisco_av_pair.cts-environment-data		keyword
cisco_ise.log.cisco_av_pair.cts-environment-version		keyword
cisco_ise.log.cisco_av_pair.cts-pac-opaque		keyword
cisco_ise.log.class		keyword
cisco_ise.log.client.latency		long
cisco_ise.log.cmdset		keyword
cisco_ise.log.component		keyword
cisco_ise.log.config_change.data		keyword
cisco_ise.log.config_version.id		long
cisco_ise.log.connectivity		keyword
cisco_ise.log.cpm.session.id		keyword
cisco_ise.log.currentid.store_name		keyword
cisco_ise.log.delta.radius.request.count		long
cisco_ise.log.delta.tacacs.request.count		long
cisco_ise.log.detailed_info		text
cisco_ise.log.details		keyword
cisco_ise.log.device.name		keyword
cisco_ise.log.device.registration_status		keyword
cisco_ise.log.device.type		keyword
cisco_ise.log.dtls_support		keyword
cisco_ise.log.eap.authentication		keyword
cisco_ise.log.eap.chaining_result		keyword
cisco_ise.log.eap.tunnel		keyword
cisco_ise.log.eap_key.name		keyword
cisco_ise.log.enable.flag		keyword
cisco_ise.log.endpoint.coa		keyword
cisco_ise.log.endpoint.mac.address		keyword
cisco_ise.log.endpoint.policy		keyword
cisco_ise.log.endpoint.profiler		keyword
cisco_ise.log.endpoint.purge.id		keyword
cisco_ise.log.endpoint.purge.rule		keyword
cisco_ise.log.endpoint.purge.scheduletype		keyword
cisco_ise.log.ep.identity_group		keyword
cisco_ise.log.ep.mac.address		keyword
cisco_ise.log.error.message		keyword
cisco_ise.log.error_message		keyword
cisco_ise.log.event.timestamp		date
cisco_ise.log.failure.flag		boolean
cisco_ise.log.failure.reason		keyword
cisco_ise.log.failure_reason		keyword
cisco_ise.log.feed_service.feed.name		keyword
cisco_ise.log.feed_service.feed.version		keyword
cisco_ise.log.feed_service.host		keyword
cisco_ise.log.feed_service.port		keyword
cisco_ise.log.feed_service.query.from_time		date
cisco_ise.log.feed_service.query.to_time		date
cisco_ise.log.file.name		keyword
cisco_ise.log.first_name		keyword
cisco_ise.log.framed.ip		ip
cisco_ise.log.framed.mtu		long
cisco_ise.log.groups.process_failure		boolean
cisco_ise.log.guest.user.name		keyword
cisco_ise.log.identity.group		keyword
cisco_ise.log.identity.policy.matched.rule		keyword
cisco_ise.log.identity.selection.matched.rule		keyword
cisco_ise.log.ipsec		keyword
cisco_ise.log.is_third_party_device_flow		boolean
cisco_ise.log.ise.policy.set_name		keyword
cisco_ise.log.last_name		keyword
cisco_ise.log.local_logging		keyword
cisco_ise.log.location		keyword
cisco_ise.log.log_details		flattened
cisco_ise.log.log_error.message		keyword
cisco_ise.log.log_severity_level		keyword
cisco_ise.log.logger.name		keyword
cisco_ise.log.message.code		keyword
cisco_ise.log.message.description		text
cisco_ise.log.message.id		keyword
cisco_ise.log.message.text		keyword
cisco_ise.log.misconfigured.client.fix.reason		keyword
cisco_ise.log.model.name		keyword
cisco_ise.log.nas.identifier		keyword
cisco_ise.log.nas.ip		ip
cisco_ise.log.nas.port.id		keyword
cisco_ise.log.nas.port.number		long
cisco_ise.log.nas.port.type		keyword
cisco_ise.log.nas_identifier		keyword
cisco_ise.log.nas_ip_address		keyword
cisco_ise.log.network.device.groups		keyword
cisco_ise.log.network.device.name		keyword
cisco_ise.log.network.device.profile		keyword
cisco_ise.log.network.device.profile_id		keyword
cisco_ise.log.network.device.profile_name		keyword
cisco_ise.log.network_device_ip		ip
cisco_ise.log.network_device_name		keyword
cisco_ise.log.object.internal.id		keyword
cisco_ise.log.object.name		keyword
cisco_ise.log.object.type		keyword
cisco_ise.log.objects.purged		keyword
cisco_ise.log.openssl.error.message		keyword
cisco_ise.log.openssl.error.stack		keyword
cisco_ise.log.operation.id		keyword
cisco_ise.log.operation.status		keyword
cisco_ise.log.operation.type		keyword
cisco_ise.log.operation_counters.counters		flattened
cisco_ise.log.operation_counters.original		text
cisco_ise.log.operation_message.text		keyword
cisco_ise.log.original.user.name		keyword
cisco_ise.log.policy.type		keyword
cisco_ise.log.port		keyword
cisco_ise.log.portal.name		keyword
cisco_ise.log.posture.assessment.status		keyword
cisco_ise.log.privilege.level		long
cisco_ise.log.probe		keyword
cisco_ise.log.profiler.server		keyword
cisco_ise.log.protocol		keyword
cisco_ise.log.psn.hostname		keyword
cisco_ise.log.radius.flow.type		keyword
cisco_ise.log.radius.packet.type		keyword
cisco_ise.log.radius_identifier		long
cisco_ise.log.radius_packet.type		keyword
cisco_ise.log.request.latency		long
cisco_ise.log.request.received_time		date
cisco_ise.log.request_response.type		keyword
cisco_ise.log.response		flattened
cisco_ise.log.segment.number		long
cisco_ise.log.segment.total		long
cisco_ise.log.selected.access.service		keyword
cisco_ise.log.selected.authentication.identity_stores		keyword
cisco_ise.log.selected.authorization.profiles		keyword
cisco_ise.log.sequence.number		long
cisco_ise.log.server.name		keyword
cisco_ise.log.server.type		keyword
cisco_ise.log.service.argument		keyword
cisco_ise.log.service.name		keyword
cisco_ise.log.service.type		keyword
cisco_ise.log.session.timeout		long
cisco_ise.log.severity.level		long
cisco_ise.log.software.version		keyword
cisco_ise.log.state		text
cisco_ise.log.static.assignment		boolean
cisco_ise.log.status		keyword
cisco_ise.log.step		keyword
cisco_ise.log.step_data		keyword
cisco_ise.log.step_latency		keyword
cisco_ise.log.sysstats.acs.process.health		flattened
cisco_ise.log.sysstats.cpu.count		long
cisco_ise.log.sysstats.process_memory_mb		long
cisco_ise.log.sysstats.utilization.cpu		double
cisco_ise.log.sysstats.utilization.disk.io		double
cisco_ise.log.sysstats.utilization.disk.space		keyword
cisco_ise.log.sysstats.utilization.load_avg		double
cisco_ise.log.sysstats.utilization.memory		double
cisco_ise.log.sysstats.utilization.network		keyword
cisco_ise.log.tls.cipher		keyword
cisco_ise.log.tls.version		keyword
cisco_ise.log.total.authen.latency		long
cisco_ise.log.total.failed_attempts		long
cisco_ise.log.total.failed_time		long
cisco_ise.log.tunnel.medium.type		keyword
cisco_ise.log.tunnel.private.group_id		keyword
cisco_ise.log.tunnel.type		keyword
cisco_ise.log.type		keyword
cisco_ise.log.undefined_52		keyword
cisco_ise.log.usecase		keyword
cisco_ise.log.user.type		keyword
cisco_ise.log.workflow		flattened
client.geo.city_name	City name.	keyword
client.geo.continent_code	Two-letter code representing continent's name.	keyword
client.geo.continent_name	Name of the continent.	keyword
client.geo.country_iso_code	Country ISO code.	keyword
client.geo.country_name	Country name.	keyword
client.geo.location	Longitude and latitude.	geo_point
client.geo.name	User-defined description of a location, at the level of granularity they care about. Could be the name of their data centers, the floor number, if this describes a local physical entity, city names. Not typically used in automated geolocation.	keyword
client.geo.postal_code	Postal code associated with the location. Values appropriate for this field may also be known as a postcode or ZIP code and will vary widely from country to country.	keyword
client.geo.region_iso_code	Region ISO code.	keyword
client.geo.region_name	Region name.	keyword
client.geo.timezone	The time zone of the location, such as IANA time zone name.	keyword
client.ip	IP address of the client (IPv4 or IPv6).	ip
client.mac	MAC address of the client. The notation format from RFC 7042 is suggested: Each octet (that is, 8-bit byte) is represented by two [uppercase] hexadecimal digits giving the value of the octet as an unsigned integer. Successive octets are separated by a hyphen.	keyword
client.port	Port of the client.	long
client.user.name	Short name or login of the user.	keyword
client.user.name.text	Multi-field of `client.user.name`.	match_only_text
cloud.account.id	The cloud account or organization id used to identify different entities in a multi-tenant environment. Examples: AWS account id, Google Cloud ORG Id, or other unique identifier.	keyword
cloud.availability_zone	Availability zone in which this host is running.	keyword
cloud.image.id	Image ID for the cloud instance.	keyword
cloud.instance.id	Instance ID of the host machine.	keyword
cloud.instance.name	Instance name of the host machine.	keyword
cloud.machine.type	Machine type of the host machine.	keyword
cloud.project.id	Name of the project in Google Cloud.	keyword
cloud.provider	Name of the cloud provider. Example values are aws, azure, gcp, or digitalocean.	keyword
cloud.region	Region in which this host is running.	keyword
container.id	Unique container id.	keyword
container.image.name	Name of the image the container was built on.	keyword
container.labels	Image labels.	object
container.name	Container name.	keyword
data_stream.dataset	Data stream dataset.	constant_keyword
data_stream.namespace	Data stream namespace.	constant_keyword
data_stream.type	Data stream type.	constant_keyword
destination.address	Some event destination addresses are defined ambiguously. The event will sometimes list an IP, a domain or a unix socket. You should always store the raw address in the `.address` field. Then it should be duplicated to `.ip` or `.domain`, depending on which one it is.	keyword
destination.as.number	Unique number allocated to the autonomous system. The autonomous system number (ASN) uniquely identifies each network on the Internet.	long
destination.as.organization.name	Organization name.	keyword
destination.as.organization.name.text	Multi-field of `destination.as.organization.name`.	match_only_text
destination.bytes	Bytes sent from the destination to the source.	long
destination.domain	The domain name of the destination system. This value may be a host name, a fully qualified domain name, or another host naming format. The value may derive from the original event or be added from enrichment.	keyword
destination.geo.city_name	City name.	keyword
destination.geo.continent_code	Two-letter code representing continent's name.	keyword
destination.geo.continent_name	Name of the continent.	keyword
destination.geo.country_iso_code	Country ISO code.	keyword
destination.geo.country_name	Country name.	keyword
destination.geo.location	Longitude and latitude.	geo_point
destination.geo.name	User-defined description of a location, at the level of granularity they care about. Could be the name of their data centers, the floor number, if this describes a local physical entity, city names. Not typically used in automated geolocation.	keyword
destination.geo.postal_code	Postal code associated with the location. Values appropriate for this field may also be known as a postcode or ZIP code and will vary widely from country to country.	keyword
destination.geo.region_iso_code	Region ISO code.	keyword
destination.geo.region_name	Region name.	keyword
destination.geo.timezone	The time zone of the location, such as IANA time zone name.	keyword
destination.ip	IP address of the destination (IPv4 or IPv6).	ip
destination.nat.ip	Translated ip of destination based NAT sessions (e.g. internet to private DMZ) Typically used with load balancers, firewalls, or routers.	ip
destination.nat.port	Port the source session is translated to by NAT Device. Typically used with load balancers, firewalls, or routers.	long
destination.packets	Packets sent from the destination to the source.	long
destination.port	Port of the destination.	long
destination.user.name	Short name or login of the user.	keyword
destination.user.name.text	Multi-field of `destination.user.name`.	match_only_text
ecs.version	ECS version this event conforms to. `ecs.version` is a required field and must exist in all events. When querying across multiple indices -- which may conform to slightly different ECS versions -- this field lets integrations adjust to the schema version of the events.	keyword
event.category	This is one of four ECS Categorization Fields, and indicates the second level in the ECS category hierarchy. `event.category` represents the "big buckets" of ECS categories. For example, filtering on `event.category:process` yields all events relating to process activity. This field is closely related to `event.type`, which is used as a subcategory. This field is an array. This will allow proper categorization of some events that fall in multiple categories.	keyword
event.code	Identification code for this event, if one exists. Some event sources use event codes to identify messages unambiguously, regardless of message language or wording adjustments over time. An example of this is the Windows Event ID.	keyword
event.created	`event.created` contains the date/time when the event was first read by an agent, or by your pipeline. This field is distinct from `@timestamp` in that `@timestamp` typically contain the time extracted from the original event. In most situations, these two timestamps will be slightly different. The difference can be used to calculate the delay between your source generating an event, and the time when your agent first processed it. This can be used to monitor your agent's or pipeline's ability to keep up with your event source. In case the two timestamps are identical, `@timestamp` should be used.	date
event.dataset	Event dataset.	constant_keyword
event.kind	This is one of four ECS Categorization Fields, and indicates the highest level in the ECS category hierarchy. `event.kind` gives high-level information about what type of information the event contains, without being specific to the contents of the event. For example, values of this field distinguish alert events from metric events. The value of this field can be used to inform how these kinds of events should be handled. They may warrant different retention, different access control, it may also help understand whether the data is coming in at a regular interval or not.	keyword
event.module	Event module.	constant_keyword
event.original	Raw text message of entire event. Used to demonstrate log integrity or where the full log message (before splitting it up in multiple parts) may be required, e.g. for reindex. This field is not indexed and doc_values are disabled. It cannot be searched, but it can be retrieved from `_source`. If users wish to override this and index this field, please see `Field data types` in the `Elasticsearch Reference`.	keyword
event.sequence	Sequence number of the event. The sequence number is a value published by some event sources, to make the exact ordering of events unambiguous, regardless of the timestamp precision.	long
event.type	This is one of four ECS Categorization Fields, and indicates the third level in the ECS category hierarchy. `event.type` represents a categorization "sub-bucket" that, when used along with the `event.category` field values, enables filtering events down to a level appropriate for single visualization. This field is an array. This will allow proper categorization of some events that fall in multiple event types.	keyword
host.architecture	Operating system architecture.	keyword
host.containerized	If the host is a container.	boolean
host.domain	Name of the domain of which the host is a member. For example, on Windows this could be the host's Active Directory domain or NetBIOS domain name. For Linux this could be the domain of the host's LDAP provider.	keyword
host.geo.city_name	City name.	keyword
host.geo.continent_code	Two-letter code representing continent's name.	keyword
host.geo.continent_name	Name of the continent.	keyword
host.geo.country_iso_code	Country ISO code.	keyword
host.geo.country_name	Country name.	keyword
host.geo.location	Longitude and latitude.	geo_point
host.geo.name	User-defined description of a location, at the level of granularity they care about. Could be the name of their data centers, the floor number, if this describes a local physical entity, city names. Not typically used in automated geolocation.	keyword
host.geo.postal_code	Postal code associated with the location. Values appropriate for this field may also be known as a postcode or ZIP code and will vary widely from country to country.	keyword
host.geo.region_iso_code	Region ISO code.	keyword
host.geo.region_name	Region name.	keyword
host.geo.timezone	The time zone of the location, such as IANA time zone name.	keyword
host.hostname	Hostname of the host. It normally contains what the `hostname` command returns on the host machine.	keyword
host.id	Unique host id. As hostname is not always unique, use values that are meaningful in your environment. Example: The current usage of `beat.name`.	keyword
host.ip	Host ip addresses.	ip
host.mac	Host mac addresses.	keyword
host.name	Name of the host. It can contain what `hostname` returns on Unix systems, the fully qualified domain name, or a name specified by the user. The sender decides which value to use.	keyword
host.os.build	OS build information.	keyword
host.os.codename	OS codename, if any.	keyword
host.os.family	OS family (such as redhat, debian, freebsd, windows).	keyword
host.os.kernel	Operating system kernel version as a raw string.	keyword
host.os.name	Operating system name, without the version.	keyword
host.os.name.text	Multi-field of `host.os.name`.	text
host.os.platform	Operating system platform (such centos, ubuntu, windows).	keyword
host.os.version	Operating system version as a raw string.	keyword
host.type	Type of host. For Cloud providers this can be the machine type like `t2.medium`. If vm, this could be the container, for example, or other information meaningful in your environment.	keyword
input.type	Input type	keyword
log.file.device_id	ID of the device containing the filesystem where the file resides.	keyword
log.file.fingerprint	The sha256 fingerprint identity of the file when fingerprinting is enabled.	keyword
log.file.idxhi	The high-order part of a unique identifier that is associated with a file. (Windows-only)	keyword
log.file.idxlo	The low-order part of a unique identifier that is associated with a file. (Windows-only)	keyword
log.file.inode	Inode number of the log file.	keyword
log.file.path	Full path to the log file this event came from, including the file name. It should include the drive letter, when appropriate. If the event wasn't read from a log file, do not populate this field.	keyword
log.file.vol	The serial number of the volume that contains a file. (Windows-only)	keyword
log.level	Original log level of the log event. If the source of the event provides a log level or textual severity, this is the one that goes in `log.level`. If your source doesn't specify one, you may put your event transport's severity here (e.g. Syslog severity). Some examples are `warn`, `err`, `i`, `informational`.	keyword
log.logger	The name of the logger inside an application. This is usually the name of the class which initialized the logger, or can be a custom name.	keyword
log.offset	Log offset	long
log.source.address	Source address from which the log event was read / sent from.	keyword
log.syslog.priority	Syslog numeric priority of the event, if available. According to RFCs 5424 and 3164, the priority is 8 * facility + severity. This number is therefore expected to contain a value between 0 and 191.	long
log.syslog.severity.name	The Syslog numeric severity of the log event, if available. If the event source publishing via Syslog provides a different severity value (e.g. firewall, IDS), your source's text severity should go to `log.level`. If the event source does not specify a distinct severity, you can optionally copy the Syslog severity to `log.level`.	keyword
message	For log events the message field contains the log message, optimized for viewing in a log viewer. For structured logs without an original message field, other fields can be concatenated to form a human-readable summary of the event. If multiple messages exist, they can be combined into one message.	match_only_text
network.protocol	In the OSI Model this would be the Application Layer protocol. For example, `http`, `dns`, or `ssh`. The field value must be normalized to lowercase for querying.	keyword
related.hosts	All hostnames or other host identifiers seen on your event. Example identifiers include FQDNs, domain names, workstation names, or aliases.	keyword
related.ip	All of the IPs seen on your event.	ip
related.user	All the user names or other user identifiers seen on the event.	keyword
server.address	Some event server addresses are defined ambiguously. The event will sometimes list an IP, a domain or a unix socket. You should always store the raw address in the `.address` field. Then it should be duplicated to `.ip` or `.domain`, depending on which one it is.	keyword
server.mac	MAC address of the server. The notation format from RFC 7042 is suggested: Each octet (that is, 8-bit byte) is represented by two [uppercase] hexadecimal digits giving the value of the octet as an unsigned integer. Successive octets are separated by a hyphen.	keyword
service.type	The type of the service data is collected from. The type can be used to group and correlate logs and metrics from one service type. Example: If logs or metrics are collected from Elasticsearch, `service.type` would be `elasticsearch`.	keyword
source.address	Some event source addresses are defined ambiguously. The event will sometimes list an IP, a domain or a unix socket. You should always store the raw address in the `.address` field. Then it should be duplicated to `.ip` or `.domain`, depending on which one it is.	keyword
source.as.number	Unique number allocated to the autonomous system. The autonomous system number (ASN) uniquely identifies each network on the Internet.	long
source.as.organization.name	Organization name.	keyword
source.as.organization.name.text	Multi-field of `source.as.organization.name`.	match_only_text
source.bytes	Bytes sent from the source to the destination.	long
source.domain	The domain name of the source system. This value may be a host name, a fully qualified domain name, or another host naming format. The value may derive from the original event or be added from enrichment.	keyword
source.geo.city_name	City name.	keyword
source.geo.continent_code	Two-letter code representing continent's name.	keyword
source.geo.continent_name	Name of the continent.	keyword
source.geo.country_iso_code	Country ISO code.	keyword
source.geo.country_name	Country name.	keyword
source.geo.location	Longitude and latitude.	geo_point
source.geo.name	User-defined description of a location, at the level of granularity they care about. Could be the name of their data centers, the floor number, if this describes a local physical entity, city names. Not typically used in automated geolocation.	keyword
source.geo.postal_code	Postal code associated with the location. Values appropriate for this field may also be known as a postcode or ZIP code and will vary widely from country to country.	keyword
source.geo.region_iso_code	Region ISO code.	keyword
source.geo.region_name	Region name.	keyword
source.geo.timezone	The time zone of the location, such as IANA time zone name.	keyword
source.ip	IP address of the source (IPv4 or IPv6).	ip
source.nat.ip	Translated ip of source based NAT sessions (e.g. internal client to internet) Typically connections traversing load balancers, firewalls, or routers.	ip
source.nat.port	Translated port of source based NAT sessions. (e.g. internal client to internet) Typically used with load balancers, firewalls, or routers.	long
source.packets	Packets sent from the source to the destination.	long
source.port	Port of the source.	long
source.user.group.name	Name of the group.	keyword
source.user.name	Short name or login of the user.	keyword
source.user.name.text	Multi-field of `source.user.name`.	match_only_text
tags	List of keywords used to tag each event.	keyword
user.full_name	User's full name, if available.	keyword
user.full_name.text	Multi-field of `user.full_name`.	match_only_text
user.name	Short name or login of the user.	keyword
user.name.text	Multi-field of `user.name`.	match_only_text

Changelog

Version	Details	Kibana version(s)
1.26.1	Bug fix (View pull request) Updated SSL description in package manifest.yml to be uniform and to include links to documentation.	8.11.0 or higher 9.0.0 or higher
1.26.0	Enhancement (View pull request) Support stack version 9.0.	8.11.0 or higher 9.0.0 or higher
1.25.0	Enhancement (View pull request) ECS version updated to 8.17.0.	8.11.0 or higher
1.24.2	Bug fix (View pull request) Revert mapping change for cisco_av_pair that was introduced with 1.24.1.	8.11.0 or higher
1.24.1	Bug fix (View pull request) Fix multiple pipeline processing issues.	8.11.0 or higher
1.24.0	Enhancement (View pull request) Improve ECS mappings by setting client.mac and event.outcome.	8.11.0 or higher
1.23.2	Bug fix (View pull request) Use triple-brace Mustache templating when referencing variables in ingest pipelines.	8.11.0 or higher
1.23.1	Bug fix (View pull request) Use triple-brace Mustache templating when referencing variables in ingest pipelines.	8.11.0 or higher
1.23.0	Enhancement (View pull request) Allow @custom pipeline access to event.original without setting preserve_original_event.	8.11.0 or higher
1.22.4	Bug fix (View pull request) Improve handling of empty data fields	8.7.1 or higher
1.22.3	Enhancement (View pull request) Fix the Cisco_ISE toggle description for filestream input	8.7.1 or higher
1.22.2	Enhancement (View pull request) Handle logs that start with ISO8601 timestamp	8.7.1 or higher
1.22.1	Enhancement (View pull request) Make Cisco ISE syslog priority field optional	8.7.1 or higher
1.22.0	Enhancement (View pull request) Update package spec to 3.0.3.	8.7.1 or higher
1.21.4	Bug fix (View pull request) Remove duplicate 'event.code' 60077 from list for category mapping.	8.7.1 or higher
1.21.3	Bug fix (View pull request) Fix ingest pipeline conditional field handling.	8.7.1 or higher
1.21.2	Enhancement (View pull request) Changed owners	8.7.1 or higher
1.21.1	Bug fix (View pull request) Fix exclude_files pattern.	8.7.1 or higher
1.21.0	Enhancement (View pull request) Handle CISE-Alarm events.	8.7.1 or higher
1.20.0	Enhancement (View pull request) ECS version updated to 8.11.0.	8.7.1 or higher
1.19.0	Enhancement (View pull request) Improve 'event.original' check to avoid errors if set.	8.7.1 or higher
1.18.0	Enhancement (View pull request) Add field event.code to capture the cisco_ise.log.message.code.	8.7.1 or higher
1.17.0	Enhancement (View pull request) Adapt fields for changes in file system info	8.7.1 or higher
1.16.0	Enhancement (View pull request) ECS version updated to 8.10.0.	8.7.1 or higher
1.15.0	Enhancement (View pull request) The format_version in the package manifest changed from 2.11.0 to 3.0.0. Removed dotted YAML keys from package manifest. Added 'owner.type: elastic' to package manifest.	8.7.1 or higher
1.14.0	Enhancement (View pull request) Add tags.yml file so that integration's dashboards and saved searches are tagged with "Security Solution" and displayed in the Security Solution UI.	8.7.1 or higher
1.13.0	Enhancement (View pull request) Update package-spec to 2.10.0.	8.7.1 or higher
1.12.0	Enhancement (View pull request) Add support for filestream input.	8.7.1 or higher
1.11.1	Bug fix (View pull request) Add missing ECS field mappings	8.7.1 or higher
1.11.0	Enhancement (View pull request) Update package to ECS 8.9.0.	8.7.1 or higher
1.10.0	Enhancement (View pull request) Convert dashboard to lens.	8.7.1 or higher
1.9.0	Enhancement (View pull request) Ensure event.kind is correctly set for pipeline errors.	7.17.0 or higher 8.0.0 or higher
1.8.0	Enhancement (View pull request) Update package to ECS 8.8.0.	7.17.0 or higher 8.0.0 or higher
1.7.0	Enhancement (View pull request) Update package to ECS 8.7.0.	7.17.0 or higher 8.0.0 or higher
1.6.1	Enhancement (View pull request) Added categories and/or subcategories.	7.17.0 or higher 8.0.0 or higher
1.6.0	Enhancement (View pull request) Update package to ECS 8.6.0.	7.17.0 or higher 8.0.0 or higher
1.5.0	Enhancement (View pull request) Add `udp_options` to the UDP input.	7.17.0 or higher 8.0.0 or higher
1.4.0	Enhancement (View pull request) Update Aggregation visualizations to Lens, Add an on_failure processor to the convert and date processors, remove unnecessary white spaces, and convert double quotes to single quotes.	7.17.0 or higher 8.0.0 or higher
1.3.0	Enhancement (View pull request) Enhancements, refacturing and bugfixes	7.17.0 or higher 8.0.0 or higher
1.2.0	Enhancement (View pull request) Update package to ECS 8.5.0.	7.17.0 or higher 8.0.0 or higher
1.1.2	Bug fix (View pull request) Fix handling of IdentityPolicyMatchedRule and IdentitySelectionMatchedRule.	7.17.0 or higher 8.0.0 or higher
1.1.1	Bug fix (View pull request) Remove duplicate fields.	7.17.0 or higher 8.0.0 or higher
1.1.0	Enhancement (View pull request) Allow non-numeric task ID fields to be ingested	7.17.0 or higher 8.0.0 or higher
1.0.0	Enhancement (View pull request) Make GA	7.17.0 or higher 8.0.0 or higher
0.3.0	Enhancement (View pull request) Update package to ECS 8.4.0.	—
0.2.0	Enhancement (View pull request) Update package to ECS 8.3.0.	—
0.1.0	Enhancement (View pull request) Initial draft of the package.	—
